Display 10 FHD’s Display mode is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device.

This model is composed of a TFT LCD panel and a driving circuit. This TFT LCD has a 10.1(16:10) inch diagonally measured active display area with (1200 horizontal by 1920 vertical pixel) resolution.

Specification

・ Panel Size: 10.1 inch

・ Compatible with NTSC & PAL system

・ Image Reversion: UP/DOWN and LEFT/RIGHT

・ ROHS design

・ Outline Dimension: 155(H) x 246.16(V) x 5.95(D) mm

・ Display area: 135.36(H) x 216.58 (V) mm

・ Number of Pixel: 1200RGB (H) x 1920 (V) pixels

・ Pixel pitch: 0.0564 (H) x 0.1692(V)s mm

・ Pixel arrangement: RGB Vertical stripe

・ Display mode: Normally Black

・ Color Filter Array: RGB vertical stripes

・ Backlight: White LED

・ Electrical Interface: MIPI
